Measure up to of 8 values
Simultaneously imaging of cornea and retina in high definition
All-in-one design, no extra PC required
Built-in IOL power calculation
User-friendly operation
*Please contact us for availability in your country.
Complete optical biometry
Visualizable fixation check
To obtain reliable axial length values, fixation is important during measurement. Colombo allows you to visually verify your measurement, the alignment can be driven to the center of macula. This helps to increase the repeatability of measurement for those patients with poor visual acuity.
More information for retina condition
SD-OCT based optical biometer
Axial length
Measurement range
12.1 mm – 38.0mm
SD of repeatability
±20um
Display resolution
10um
Central corneal thickness
Measurement range
0.2mm-1.4mm
SD of repeatability
±10 um
Display resolution
0.1 um
Corneal diopter
Measurement range
28.1D-84.3D
SD of repeatability
±0.25D
Display resolution
0.01D
Anterior chamber depth
Measurement range
0.7mm-6.0mm
SD of repeatability
±0.01mm
Display resolution
0.01mm
Pupil diameter
Measurement range
0.5mm-13.5mm
SD of repeatability
±0.09mm
Display resolution
0.01mm
White-to-white
Measurement range
6-16mm
SD of repeatability
±0.1mm
Display resolution
0.01mm
Axis angle
Measurement range
1 º-180 º
SD of repeatability
±5 º
Display resolution
1 º
OCT imaging resolution
5μm
OCT scan range
6mm
Retina thickness measurement
Yes
Display size
10.1inch touch screening(support external display)
