Optical Biometer

  • Complete optical biometry

    The Colombo measures up to 8 values, including axial length, corneal curvature radius, anterior chamber depth, central corneal thickness, white-to-white distance, pupil size, retinal thickness, and lens thickness (lens thickness is only available in Colombo IOL II)

  • Visualizable fixation check

    To obtain reliable axial length values, fixation is important during measurement. Colombo allows you to visually verify your measurement, the alignment can be driven to the center of macula. This helps to increase the repeatability of measurement for those patients with poor visual acuity.

  • More information for retina condition

    Although Colombo is not designed for diagnosis of retinal disease, but the high resolution images can offer a basic screening of macular pathology before cataract surgery, which is beneficial for both patients and doctors.

Complete optical biometry

Visualizable fixation check

More information for retina condition
  • Image gallery
  • Video
  • Specifications
  • Downloads

  •

    Colombo

  •

    AXL

  •

    software interface

SD-OCT based optical biometer

  • Axial length

  • Measurement range

  • 12.1 mm – 38.0mm

  • SD of repeatability

  • ±20um

  • Display resolution

  • 10um

  • Central corneal thickness

  • Measurement range

  • 0.2mm-1.4mm

  • SD of repeatability

  • ±10 um

  • Display resolution

  • 0.1 um

  • Corneal diopter

  • Measurement range

  • 28.1D-84.3D

  • SD of repeatability

  • ±0.25D

  • Display resolution

  • 0.01D

  • Anterior chamber depth

  • Measurement range

  • 0.7mm-6.0mm

  • SD of repeatability

  • ±0.01mm

  • Display resolution

  • 0.01mm

  • Pupil diameter

  • Measurement range

  • 0.5mm-13.5mm

  • SD of repeatability

  • ±0.09mm

  • Display resolution

  • 0.01mm

  • White-to-white

  • Measurement range

  • 6-16mm

  • SD of repeatability

  • ±0.1mm

  • Display resolution

  • 0.01mm

  • Axis angle

  • Measurement range

  • 1 º-180 º

  • SD of repeatability

  • ±5 º

  • Display resolution

  • 1 º

  • OCT imaging resolution

  • 5μm

  • OCT scan range

  • 6mm

  • Retina thickness measurement

  • Yes

  • Display size

  • 10.1inch touch screening（support external display）
